- Size: 120
- Place of Origin: China Shandong
- Brand Name: PECIAL TRAILER
- Model Number: GJC9400ZZX
- Weight: 7000.000 kg
Chassis | Dimension | 11500,11000mm*2500mm*3050mm |
Chassis | Opting for high tensile steel Q235; The height of beam: 500mm; Top plate:18mm; Bottom plate:20mm; Middle plate:12mma; Side beam:16# channel steel;Through beam:14# channel steel. | |
Loading Capacity | 32Tons | |
Floor Steel | 3mm diamond steel. | |
King Pin | 3.5’’standard bolted style . | |
Landing Gear | JOST brand C200 landing gear. | |
Suspension | Suspension Type | A couple of American style mechanical 3 axles suspension, 60#. |
Steel Spring | 10 piece leaf spring, 90*13mm. | |
Running System | Axle | 3 units FUWA brand 13T. |
Tyre | 13 units of 12R22.5 tubeless tyre. | |
Wheel Rim | 13 units of 9.0*22.5 wheel rim. | |
Brake System | Brake Valve | 2 sets WABCO RE 6 relay valve. |
Brake Chamber | T30/30 spring brake chamber. | |
Air tank | 45L air tank. | |
Brake System | Dual line brake system. | |
Electric | Socket | International standard 24V circuit 7-pin ISO socket. |
Light | LED tail lamp with turn signal, brake light & reflector, side lamp etc. | |
Other | Painting | Sand blasting processing clean rust, 1 coat of anticorrosive primer, 2 coat of finish. |
Tool Box | One tool box with a set of standard trailer tool. | |
Spare Tyre | One spare tyre holder. | |
Package | Ship by 40HQ container.
|
