- Size: 120
- Place of Origin: China ShanDong
- Brand Name: PECIAL TRAILER
- Model Number: GJC9401ZZX
- Weight: 8500.000 kg
Main Dimensions | |
Dimension | 11280*2495*3970mm ( outside) 10500*2300*1700mm (work space ) |
Tare weight | About 15600KGS |
Total Volume（m3） | 30 m3 or less than 50tons |
Side wall thickness（mm） | 2.3mm Q235 steel (three or five door opening door ) |
Bottom plate thickness(mm) | 3mm diamond plate /Q235 steel |
Lifting system | Full set of Hydraulic Lifting system (Four diameter125 lifting cylinder, and one diameter140 lifting cylinder.) |
Chassis | |
Main Beams | Height:500mm, upper plate is 16mm,middle is 8mm(double three plate),down plate is 18mm,material is Q345B steel |
Axle | 3 axles, FUWA/HUAJING brand 13tons or 16tons per axles |
Landing Gear | JOST (D200T）or CHINA BRAND 28T |
King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
Suspension | Mechanical suspension (Germany Type or America Type) Or Air suspension ( |
Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 |
Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; 1 piece of 45L air tanks. |
Rim | 9.00-22.5/8.00-20/8.5-20 |
Tire | 12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional |
ABS | Optional |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Accessories | One standard tool box |
Shipping Terms | By Bulk Cargo or roro, the trailer size can be design according to your special requirement, the tractor truck can be choose 6*4 model. |
