- Size: 130
- Place of Origin: China ShanDong
- Brand Name: PECIAL TRAILER
- Model Number: GJC9401CCY
- Weight: 6000.000 kg
Tare Weight | About 8.3T |
Dimension | 12000mm*2490mm*2860mm (Outer side) 11800*2300*1800mm |
Loading Capacity (T) | ≤ 30 T |
Axle | 13 T, Huajing Brand :2axles |
Rim | 9.00-22.5 (special for export market) |
Tire | 12.00R22.5 (special for export market). 9pieces |
Suspension | Mechanical suspension ( America Type) (special for export market) |
Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer (special for export market) |
King pin | JOST brand 2.0 or 3.5inch bolts type |
Support leg | |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm ; Material is Q345B Steel . |
Side beam | 16mm Channel steel (Material is Q235 steel ). |
Side Wall | 1800mm ，the open door can be choose freely. With 1200mm height square tube or round tube. |
Brake chamber | WABCO RE 6 relay valve; T30/30 T30 Spring brake chamber（TKL brand）; One piece of 45L air tank |
ABS | Without |
Valve | WABCO valve |
Light | LED light |
Voltage | 24V |
Receptacle | 7 ways (7 wire harness) |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Roof | With canvas |
Shipping Terms: | By 40HQ container. Two unit trailer put into ONE 40HQ container. |
