Model Number

GJC9400GYY/GJC9401GYY/GJC9402GYY/GJC9400GRY/GJC9400GSY

Shape

Round or Square (Optional)

Dimension

9500-13500*2500*3900 (Exact size depends on the final design)

Tare Weight

About 8000KGS-12800KGS

Loading Capacity

32,000-60,000 liters

The tank body material

5mm, 6mm or 7mm Q235 Carbon steel plate//Stainless Steel

The foreside and back side head

6mm or 7mm Q235 Carbon steel plate/ Stainless Steel

Wave plate

4mm Stainless Steel

Manhole Cover

2 or 3 or 4 pieces ,Stainless steel manhole,diameter 500mm

Bottom Valve

Stainless Steel Bottom Valve

Discharging Pipe

2 pieces Rubber tube , 6m/each

Discharging Valve

Diameter is 3 or 4 inch

Compartments

Optional

Chassis

Main Beam

Steel Q345

Axle

2 or 3 axles,13T/16T,YANGJIA/FUWA/BPW Brand

King pin

2 or 3.5 inch welding or bolt-in King pin,JOST brand/China brand

Suspension

Mechanical suspension (Germany Type or America Type)

Or Air suspension (Chinabrand or BPW brand )

Leaf Spring

90mm(Width) x13mm(Thickness) x 10 layers,optional

Landing Gear

28T External Single Action,YAHUA/JOST brand

Brake Chamber

WABCO RE 6 relay valve;T30/30 T30 Spring brake chamber (TKL brand);Two pieces of 45L air tanks Or China brand

Tire

8.25R16/8.25R20/12R22.5/11.00R20/12.00R20,Chengshan/Shuangqian/Linglong/Triangle Brand

Wheel Rim

9.00-22.5/7.5-20/8.00-20/8.5-20

ABS system

Optional

Fire

Two pieces 4 KG

Spare Tire Carrier

2 pieces

Side,rear safty guard

With
